The process of selecting the correct device for starting a motor can often be a complex task due to the wide variety of devices available and their different functionalities. In this guide, we will explore whether a 63A Molded Case Circuit Breaker (MCCB) can be used as a replacement for a Direct-On-Line (DOL) starter for starting an 11kW or 15kW motor.

Table of Contents

• What is an MCCB?
• What is a DOL Starter?
• Can an MCCB Replace a DOL Starter?
• Conclusion

What is an MCCB?

An MCCB is an electrical protection device used to prevent short circuit, overload, and fault currents in electrical networks. They are designed for higher current applications and often feature adjustable trip characteristics, allowing for a broad range of applications in commercial and industrial settings.

What is a DOL Starter?

A DOL starter, or Direct-On-Line starter, is a simple motor starter that provides full-line voltage to the motor terminals. This type of starter connects the motor directly to the power supply, resulting in a sudden rush of current, known as an inrush current, at the moment of starting. DOL starters are most commonly used with smaller motors where a high starting current won't cause damage or disruption to the power supply.

Can an MCCB Replace a DOL Starter?

An MCCB and a DOL starter, while both involved in motor operation, serve fundamentally different purposes.

The primary function of an MCCB is to provide protection against overload and short circuit conditions. While an MCCB can provide some level of motor protection, it is not designed to control the motor's operation, specifically the starting process.

A DOL starter, on the other hand, is a motor control device designed specifically for starting and stopping the motor. Its key role is to manage the inrush current that occurs when the motor is started. By providing full-line voltage to the motor terminals during the starting phase, a DOL starter can effectively control the motor's starting characteristics and protect it from the potential damage caused by a sudden surge in current.

So, while a 63A MCCB can handle the currents associated with an 11kW or 15kW motor, it cannot replace a DOL starter in terms of motor control functionality. The MCCB will protect the circuit, but it will not manage the motor's starting process as a DOL starter does.

Conclusion

While MCCBs and DOL starters are both key components of many electrical systems, they serve different purposes and are not interchangeable. An MCCB provides crucial protection against overloads and short circuits, while a DOL starter controls the starting and stopping of a motor, managing the inrush current to prevent potential damage. When designing or maintaining an electrical system, understanding these differences is key to ensuring effective operation and protection.
